Check for physical damage on the switchgear
2
Check the degree of IP protection on the switchgear
3
Verify the correct wiring and connection of the switchgear
4
Examine the switchgear for correct operation
5
Test the switchgear under nominal load conditions
6
Check the insulation resistance of the switchgear
7
Verify the correct rating of the switchgear
8
Perform a mechanical operation check on the switchgear
9
Carry out a contact resistance test on the switchgear
10
Perform a high voltage test on the switchgear
11
Inspect the switchgear for proper grounding
12
Perform a temperature rise test on the switchgear
13
Check the oil level and oil leakages if applicable
14
Examine the breakers for wear and tear
15
Check the switchgear for noise and vibration
16
Carry out a functionality test on the safety devices
17
Check the labelling and markings on the switchgear
18
Review the manufacturer's documentation
19
Approval: Quality Control Officer
Check for physical damage on the switchgear
Inspect the switchgear for any physical damage or signs of wear and tear. This task is crucial to ensure the switchgear is in proper condition and will function safely. Note any damages found and document them for further analysis or repairs. Use appropriate tools such as a flashlight or magnifying glass, if needed.
1
Cracks or dents
2
Loose or missing parts
3
Visible burn marks
4
Corrosion or rust
5
Signs of overheating
Check the degree of IP protection on the switchgear
Verify the IP (Ingress Protection) code of the switchgear to ensure it has the adequate protection against solid and liquid ingress. The IP code consists of two numbers indicating the degree of protection. Use the appropriate testing equipment to check the IP rating and document the results.
1
IP20
2
IP44
3
IP55
4
IP65
5
IP68
Verify the correct wiring and connection of the switchgear
Check the wiring and connection of the switchgear to ensure they are correctly installed and secure. Inspect the connection points, terminals, and cables for any loose or damaged components. Use appropriate tools such as a multimeter or voltage tester to verify the continuity and integrity of the connections.
1
Securely tightened connections
2
Properly insulated wires
3
No loose or exposed wiring
4
Correct polarity
5
Proper grounding
Examine the switchgear for correct operation
Test the switchgear to ensure all its functions and components operate correctly. This includes verifying the functionality of switches, indicators, meters, and control mechanisms. Proceed with caution and follow the manufacturer's instructions to avoid any potential hazards. Document any abnormalities or malfunctions discovered during the examination.
1
Switches operate smoothly
2
Indicators display accurate information
3
Meters provide correct readings
4
Control mechanisms function properly
5
No unusual noises or smells
Test the switchgear under nominal load conditions
Simulate the nominal load conditions on the switchgear to evaluate its performance and stability during regular operation. Use appropriate load testing equipment and follow the prescribed load procedures. Monitor the switchgear for any abnormalities, overheating, or unexpected behavior. Record the results accurately for reference and analysis.
Check the insulation resistance of the switchgear
Measure the insulation resistance of the switchgear to ensure it meets the required standards. Use an insulation tester or megohmmeter to perform the measurement. Inspect the insulation resistance values and compare them to the specified range or threshold. Record the results for further analysis and reference.
Verify the correct rating of the switchgear
Confirm that the switchgear has the correct rating in terms of voltage, current, and power frequency. Refer to the manufacturer's specifications and labels on the switchgear. Validate the rating against the requirements of the electrical system or application. Document the verified ratings for future reference.
1
Rated voltage
2
Rated current
3
Power frequency
4
Short circuit current withstand
5
Interrupting rating
Perform a mechanical operation check on the switchgear
Manually operate the mechanical components of the switchgear, such as knobs, levers, handles, or latches, to ensure they move freely and without resistance. Inspect for any stiffness, misalignment, or other issues that may affect the switchgear's operation. Lubricate or address minor problems as necessary.
1
Smooth movement of knobs/levers
2
No resistance or stiffness
3
Proper alignment of mechanical parts
4
No loose or missing components
5
Sufficient lubrication (if applicable)
Carry out a contact resistance test on the switchgear
Perform a contact resistance test on the switchgear to ensure proper electrical contact between components. Use suitable test equipment, such as a micro-ohmmeter, to measure the resistance. Compare the measured values to the specified limits or standards. Document the results for future analysis or troubleshooting.
Perform a high voltage test on the switchgear
Conduct a high voltage test on the switchgear to evaluate its insulation integrity and electrical strength. Follow the specified procedures and safety precautions during the test. Use high voltage testing equipment capable of delivering the required voltage levels. Monitor the switchgear for any insulation breakdown or faults. Record the results accurately for analysis and compliance purposes.
Inspect the switchgear for proper grounding
Verify that the switchgear is properly grounded to ensure the safety and effectiveness of the electrical system. Check the grounding connections, grounding conductors, and grounding resistance. Measure the grounding resistance using an appropriate instrument. Document the measured resistance and confirm it is within the acceptable range.
1
Secure grounding connections
2
Adequate grounding conductors
3
Grounding resistance within limits
4
No loose or corroded grounding components
5
Proper grounding labels
Perform a temperature rise test on the switchgear
Conduct a temperature rise test on the switchgear to evaluate its thermal performance. Apply a specified load to the switchgear and monitor the temperature rise over a defined time period. Use infrared thermography or temperature sensors to measure and record the temperatures at critical points. Compare the results to the specified limits or standards.
Check the oil level and oil leakages if applicable
Inspect the switchgear's oil level and check for any potential oil leakages. If the switchgear contains oil-filled compartments or components, verify that the oil level is within the specified range. Look for any visible signs of oil leakage, such as stains, drips, or puddles. Report any abnormalities or issues for further assessment or repair.
1
Oil level within range
2
No visible oil leakages
3
Absence of oil stains or drips
4
No oil puddles or accumulation
5
Properly sealed oil compartments
Examine the breakers for wear and tear
Inspect the breakers within the switchgear for any signs of wear and tear. Check for loose connections, damaged contacts, or worn-out components. Test the proper operation of the breakers and ensure they function smoothly. Report any detected issues or abnormalities for further investigation or maintenance.
1
Properly tightened connections
2
Intact and functional contacts
3
No signs of arcing or sparking
4
No excessive heat or discoloration
5
Smooth operation of breakers
Check the switchgear for noise and vibration
Assess the switchgear for any unusual noise or vibration during its operation. Listen carefully for any abnormal sounds, such as buzzing, humming, or grinding noises. Observe for excessive vibration that may indicate loose components or mechanical issues. Note and report any perceptible noise or vibration for further analysis or correction.
1
No unusual buzzing or humming noises
2
Absence of grinding or rattling sounds
3
No excessive vibration or shaking
4
Stable and quiet operation
5
Smooth running without noise
Carry out a functionality test on the safety devices
Perform a functionality test on the safety devices installed in the switchgear, such as circuit breakers, relays, fuses, or safety interlocks. Ensure that these devices operate correctly and provide the necessary protection to the electrical system or equipment. Document any malfunctions or abnormalities discovered during the test.
1
Proper tripping of circuit breakers
2
Functional relays and interlocks
3
Intact and functional fuses
4
Appropriate response to fault conditions
5
No unexpected operation or failure
Check the labelling and markings on the switchgear
Inspect the labeling and markings on the switchgear to ensure they are accurate, legible, and match the specifications or requirements. Check for proper identification labels, rating labels, warning signs, and safety instructions. Verify that the markings are durable and resistant to fading or erasure.
1
Correct identification labels
2
Accurate rating labels
3
Legible warning signs
4
Visible safety instructions
5
Durable and resistant markings
Review the manufacturer's documentation
Review the manufacturer's documentation, such as manuals, guidelines, or specifications, related to the switchgear. Understand the recommended maintenance procedures, operating guidelines, and safety precautions. Familiarize yourself with the troubleshooting instructions and contact details for technical support. Keep the documentation accessible for future reference.
Approval: Quality Control Officer
